输出灵敏度

Rated output

1.5±20％ mV/V

零点输出

Zero balance

± 0.05 mV/V

非线性

Non-linearity

0.5%F.S.

滞后

Hysteresis

0.5%FS.

重复性

Repeatability

0.2%F.S.

蠕变(30min)

Creep(30min)

0.1%F.S.

温度灵敏度漂移

Temp. effect on output

0.05%F.S./10℃

零点温度漂移

Temp.effect on zero

0.05%F.S./10℃

输入电阻

Input impedance

800~1100 Ω

输出电阻

Output impedance

800~1100 Ω

绝缘电阻

Insulation

≥5000MΩ/100VDC

激励电压

Recommended excitation

5-15V

最大激励电压

Maxmum excitation

15V

温度补偿范围

Compensated temp range

-10~60℃

工作温度范围

Operation temp range

-20~80℃

安全超载

Safe overload

150%F.S.

极限超载

Ultimate overload

200%F.S.

材质

Material

Stainless(不锈钢)

电缆尺寸

Cable size

Ф3×3000 mm

防护等级

IP class

IP67
